Pneumatic H05VV-F TTR Cable Stripping Machine
Pneumatic H05VV-F TTR Cable Stripping Machine Peeling Outer Sheath and Insulations
Pneumatic H05VV-F TTR Cable Stripping Machine
Pneumatic H05VV-F TTR Cable Stripping Machine Peeling Outer Sheath and Insulations

Pneumatic H05VV-F Cable Stripping Machine

This pneumatic聽H05VV-F cable stripping machine is suitable for simultaneous peeling pvc outer sheath and pvc insulations of TTR multi conductor cable, such as, data cable, power cord and etc, more convenient for adjusting stripping length, comparing to manual cable peeling tool, it will save human labor and easy operation.

Categories: Tags: , , , , , , , , , ,
  • Description
  • Inquiry

This pneumatic聽TTR H05VV-F cable stripping machine is an air-operated power wire stripping machine for peeling pvc outer sheathed and insulations of TTR cable simultaneously, which increase the cable stripping productivity greatly, it’s easy operation and maintenance.

Technical聽Parameters

ModeLL-500
Power聽Supply220V聽50Hz
Size220x360x220mm
Power150W
Jacket聽Stripping聽Capacity3-10mm
Core聽Wire聽Stripping聽Length0-15mm
Jacket聽Stripping聽Length0-90mm
Core聽Wire聽Stripping聽Capacity1-8聽PCS
Air聽Pressure4-7KG
Weight28KG
?rel=0
