Technical parameters of equipment:
Model: LB-2.0T
Display mode: button screen.
Form factor: 460*320*460mm.
Press relay: 2.0T.
Working power supply: AC220V 50HZ.
Motor power:0.75KW
Average power consumption: 0.02KW
Feeding length parameter:1mm-99.9mm
Available wire: Electronic wire, headphone wire, LED, etc.
LB-2.0T Wire Splice Band Machine
LB-2.0T automatic feeding mute wire splice band machine.
Special note:
1. Energy saving and low noise.
2. The mechanical shape design conforms to the CE standard and has high safety performance.
3. Digital debugging and feeding length, humanized operation interface is easy to understand, easy to learn and easy to use.
4. The rubber wheel is used to extrude and feed splice band harmless to ensure the machining accuracy of each wire, reduce the embossing of the wire insulation, and make the processed wire harness more perfect.
5. The mold design range is processed, and the riveting strength is enhanced.
- Description
- Inquiry
Related Products
-
1.8T Wire Splice Band Splicing Machine
- This 1.8T wire splice band splicing machine is specially designed for wire riveting processing, crimping riveting and wire connection, which replaced the traditional soldering methods to avoid faults of no cold welding, air welding and air pollution.Splice band machine widely admitted to be the most simple and effective way.
- This splice band wire crimping machine uses special continuous copper strip terminal materials to shape molding after being cut off. Pressing quickly at one time without waste and saving cost.
- Splice band is processed by residue lines. Resistance to tension is particularly strong after riveting with stable quality.
- Straight and curved mold bases can be equipped to connect with various products.
- User-friendly design, easy to operate.
-
LB-4.0T Wire Splice Band Machine
LB-4.0T automatic feeding mute wire splice band machine.
Special note:
1. Energy saving and low noise.
2. The mechanical shape design conforms to the CE standard and has high safety performance.
3. Digital debugging and feeding length, humanized operation interface is easy to understand, easy to learn and easy to use.
4. The rubber wheel is used to extrude and feed splice band harmless to ensure the machining accuracy of each wire, reduce the embossing of the wire insulation, and make the processed wire harness more perfect.
5. The mold design range is processed, and the riveting strength is enhanced. -
LBK9S 2TServo Wire Splicing Machine
Professional connector crimping equipment, designed for specifically for processing high-end, precision wire
it replaces the traditional soldering together of wires with splice band crimping, without cold solder and air pollution.With humanization design, it is easy to operate.
It adopts automatic conveyor with continuous for copper terminal (patent鈥檚 in the official records please don鈥檛 counterfeit), it can finish the processes of cutting, shaping and crimping in one time without scraps, saving cost.
The mold is customized according to the wire size and the splice band specifications, and different wire size are configured with different mold.
If the wire size is same, and the splice band size is changed, that need to accord request to do different mold.
Splice band processed by special lines, and after riveting, the tension-resistant will be particularly strong, which ensures the stable quality.
