Benchtop Multicore Cable Stripping and Crimping Machine
Effortlessly tackle multicore cables! This benchtop machine combines stripping and crimping for fast, one-step processing. Ideal for ultra-fine and shielded wires, it delivers quiet, high-speed operation with minimal power consumption. Automatic scrap removal keeps your workspace clean, and the adjustable speed control caters to all skill levels. Durable pneumatic components ensure reliable crimping for various terminals and connectors. Boost your efficiency and take wire processing to the next level!
- Description
- Inquiry
| power supply | Single phase 200V-240V50/60Hz(Can be customized) | |
| motor | 400W | |
| power | 750W | |
| air source | 0.3-0.4mpa (please use dry and clean air) | 0.5-0.6mpa (please use dry and clean air) |
| size | W530xL400xH830mm | W500xL450xH1000mm |
| weight | 70KG | 100KG |
| Applicable wire diameter | AWG36 #-AWG20 # (depending on the wire) | AWG16-AWG24 (depending on the wire) |
| Applicable wire | AV, AVS, AVSS, CAVUS, KV, KIV, UL, V Teflon, fiber wire, etc. | UL, IV Teflon, fiber thread, etc. |
| Stripping length | 1.0mm-10.0mm | 1.0mm-8.0mm |
| Tangent error | 0.05mm-0.1mm | 0.05mm-0.1mm |
| position error | 0.05mm-0.1mm | 0.05mm-0.1mm |
| Crimp terminal | Open continuous straight terminal | Open continuous straight terminal |
| Pressing ability | 1.5 tons | 2T |
| Stripping stroke | 20mm | |
